Dormer 1/4"-28 HSS-E-PM Spiral Point Plug Tap, 3 Flute, UNF, TiAlN Coated

PRODUCT DESCRIPTION

Description	Spiral Point Tap; 1/4" - 28 ; 3.15" OAL ; 3 FL ; HSSE-PM ; TiAlN ; H4 ; Series E911
Brand	Dormer
Chamfer	3.5P-5P
Coating	TiAlN/Top
Connection Diameter Machine Side Dconms	0.255"
Coolant Supply Property CSP	External
Cutting Direction Hand	Right-Hand
Cutting Edge Material	HSS-E-PM
End Shape	Spiral Point
Flute Count Nof	3
Flute Helix Angle Fha	0 Degrees
Flute Length	0.591"
Length Group	2.5xD
Measurement Type	Inch
Overall Length Oal	3.15"
Serieslist	E911
Special Feature	Red Shark
Standard	DIN|ANSI
Thread Cutting Part Length THL	0.591"
Thread Diameter Size TDZ	1/4"
Thread Size	1/4" - 28
Thread Standard	UNF
Thread Tolerance Class TCTR	H4
Threads Per Inch Tpi	28
Tool Type	Machine Tap
Trade Name	Shark Taps
