Kennametal 33/64" Carbide Drill Tip Insert KSEM0515HPL KC7320 PVD AlTiN
PRODUCT DESCRIPTION
Specifications
| Cutting Diameter (Inch) | 33/64 |
| Cutting Diameter (Decimal Inch) | 0.5157 in |
| Cutting Diameter (mm) | 13.10 |
| Tip Material | Solid Carbide |
| Manufacturer Grade | KCMS15 |
| Material Grade | Fine Grain |
| Series | KSEM |
| Coating Process | PVD |
| Insert Geometry | HPL |
| Insert Seat Size | C |
| Functional Length (Decimal Inch) | 0.2579 |
| Primary Workpiece Material | Non-Ferrous Metal; Stainless Steel; Cast Iron; Superalloys & Titanium; Steel |
| Primary Workpiece Material Code | P; S; K; M; N |
| Height (mm) | 7.00 |
| Overall Length/Projection (Decimal Inch) | 0.2579 |
| Drill Point Angle | 140 |
| Flute Type | Helical |
| Insert Holding Method | Clamp |
| ISO Number | KSEM0516HPL |
| Coolant Through | No |
| Flute Length (mm) | 7.00 |
| Point Type | Standard |
| Spiral Type | Regular Spiral |
| Style | KSEM |
| UNSPSC Code | 23242105 |
| Applications | Drilling; ToolDimensions:2flute/2margin/coolant; Drilling:InclinedExit; Drilling:StackedPlates |
| Coating/Finish | AlTiN |
| Included Angle Degree | 140 |
| Number Of Flutes | 2 |
