Kyocera 8.2mm Solid Carbide Drill Jobber Length 2 Flute 118° USA Made

Kyocera 8.2mm Solid Carbide Drill Jobber Length 2 Flute 118° USA Made

$17.16 USD
$0.00 USD $17.16 USD
Sale Sold out
Shipping calculated at checkout.
Free Shipping: Available on all orders over $75 in value, shipping to the lower 48 states. Refer to our Shipping Policy for more details.

Same-Day Shipping & Handling Cut-Off Time: Orders placed before 3:00 PM (EST) Monday through Friday, ship on the same business day.

No Returns Or Exchanges: Being in the wholesale business we offer our products at well below regular prices, for the intent of resale. Therefore, we do not accept returns or exchanges. Refer to our Refunds Policy for more details.

Low stock: 3 left
Series Description General Application Drill
High Performance No
Unit (inch/mm) mm
Number of Flutes 2
Primary Workpiece Material (P) Steel|(M) Stainless Steel|(K) Cast Iron|(N) Non-Ferrous Materials|(S) High Temp Alloy
Secondary Workpiece Material (H) Hardened Materials
Reach (xD) 5xD
Size 8.20mm
Cutting Diameter (DC) (Decimal Inch) 0.3228
Cutting Diameter (DC) (mm) 8.20
Shank Diameter (DCON) (Decimal Inch) 0.3228
Shank Diameter (DCON) (mm) 8.20
Flute Length (LCF) (Decimal Inch) 2.9528
Flute Length (LCF) (mm) 75.00
Overall Length (OAL) (Decimal Inch) 4.6063
Overall Length (OAL) (mm) 117.00
Shank Length (LS) (Decimal Inch) 1.6600
Point Angle (Degree) 118
Cutting Diameter (DC) Tolerance (Decimal Inch) +.00000 / -.00050
Cutting Diameter (DC) Tolerance (mm) +.0000 / -.0099
Shank Diameter (DCON) Tolerance (ISO) h6
Shank Type Straight
Coolant Option External Coolant
Coating Description Bright/Uncoated
Additional Geometry Right Hand Cut Direction (RHC)
Helix Angle Right Spiral
Helix Angle (Degree) 20
Variable Helix No
Center Cutting No
Chip Breaker No
DIN Standard DIN 338
Number of Margins 2
Shipping Weight 0.1420
Series 101
Weldon Flat No
