Mitutoyo 3-4" Disk Micrometer Made In Japan 123-128

Mitutoyo 3-4" Disk Micrometer Made In Japan 123-128

$54.60 USD
$0.00 USD $54.60 USD
Sale Sold out
Shipping calculated at checkout.
Free Shipping: Available on all orders over $75 in value, shipping to the lower 48 states. Refer to our Shipping Policy for more details.

Same-Day Shipping & Handling Cut-Off Time: Orders placed before 3:00 PM (EST) Monday through Friday, ship on the same business day.

No Returns Or Exchanges: Being in the wholesale business we offer our products at well below regular prices, for the intent of resale. Therefore, we do not accept returns or exchanges. Refer to our Refunds Policy for more details.

17 in stock

Mitutoyo Disk Micrometer, 3-4" - 123-128

  • Diameter of measuring disk: 20mm / .787"
  • 0.7mm / .028” (1mm: models over 100mm) edge thickness to enter narrow recesses
  • With Ratchet Stop for constant force
  • With a standard bar except for 25mm / 0 - 1” model
  • With SPC output (Series 323)
  • The Series 223 is provided with a mechanical digit counter for quick reading of measurements
  • Supplied in fitted plastic case. (Over 100mm models supplied wooden cases)


Technical Data:

Range 3 - 4"
Accuracy ± 0.0003"
Graduation 0.01mm or .001"
Flatness 1µm / .00004" for models up to 100mm / 4"
1.6µm / .000063" for models over 100mm / 4"
Parallelism 4µm / .00016" for models up to 50mm / 2"
.00024" for models up to 4"
(4+R/50)µm for models up to 100mm
(5+R/75) µm for models over 100mm, R=max.
Measurable module 0.5-6 (0.7-11: models over 100mm)
