OSG 3.4mm Solid Carbide Drill 5xD WXL Coating 2 Flute Coolant Thru 140° Point
OSG 3.4mm Solid Carbide Drill 5xD WXL Coating 2 Flute Coolant Thru 140° Point
Regular price
$16.38 USD
Regular price
$0.00 USD
Sale price
$16.38 USD
Unit price
/
per
Shipping calculated at checkout.
Low stock: 1 left
Couldn't load pickup availability
OSG
SOLID CARBIDE DRILL
| Drill Bit Size / Cutting Diameter (DC) | 3.4 mm | Cutting Edge Material | Carbide |
| Drill Bit Size / Cutting Diameter (DC) - Metric | 3.4 mm | Tool Type | Jobber Drill |
| Length Group | 5xD | Measurement Type | Metric |
| Coating | WXL | Series/List # | 5210 |
| Applicable Material | | Steel | Hard Materials | Aluminum / Non-Ferrous Materials | | Usable Length (LU) | 31 mm |
| Connection Diameter Machine Side (DCONMS) | 4 mm | Length Chip Flute (LCF) | 31 mm |
| Coolant Supply Property (CSP) | Coolant Thru | Overall Length (OAL) | 86 mm |
| Point Angle (SIG) | 140 Degrees | Flute Count (NOF) | 2 |
| Functional Length (LF) | 31 mm | Cutting Direction (HAND) | Right Hand |
