PCT 11/64" Carbide Drill 12xD Coolant Thru Triple Margin ZicroPlus Coated Drill
PCT 11/64" Carbide Drill 12xD Coolant Thru Triple Margin ZicroPlus Coated Drill
Regular price
$36.76 USD
Regular price
$0.00 USD
Sale price
$36.76 USD
Unit price
/
per
Shipping calculated at checkout.
Low stock: 4 left
Couldn't load pickup availability
PRECISION CUTTING TOOLS
USA MADE
HIGH PERFORMANCE SOLID CARBIDE COOLANT THRU DRILL TRIPLE MARGIN
| Drill Bit Size / Cutting Diameter (DC) | 0.1719 mm | Shape | Round |
| Decimal Equivalent | 0.0068″ | Cutting Edge Material | Carbide |
| Length Group | 12xD | Tool Type | Solid Carbide Drill |
| Coating | ZircoPlus | Flute Type | Helical |
| Applicable Material | Aluminum / Non-Ferrous Materials | Grade | H5006 |
| Connection Diameter Machine Side (DCONMS) | 6 mm | Measurement Type | Metric |
| Coolant Supply Property (CSP) | Coolant Thru | Series/List # | AXC |
| Point Angle (SIG) | 135 Degrees | Usable Length (LU) | 2.2619 mm |
| Flute Helix Angle (FHA) | 15 Degrees | Length Chip Flute (LCF) | 64 mm |
| Number of Teeth | 2 | Overall Length (OAL) | 102 mm |
| Shank Length (LS) | 1.496 mm | Flute Count (NOF) | 2 |
| Shank Type | Cylindrical | Feature | TRIPLE-MARGIN DRILL, COOLANT THRU |
| Shank Standard | h6 | Cutting Direction (HAND) | Right Hand |
