Michigan Wholesale Tool Supply
Sandvik CoroDrill 8mm Solid Carbide Drill 5xD PVD TiAlN Coating Coolant Thru
Sandvik CoroDrill 8mm Solid Carbide Drill 5xD PVD TiAlN Coating Coolant Thru
Regular price
$29.12 USD
Regular price
$0.00 USD
Sale price
$29.12 USD
Unit price
/
per
Shipping calculated at checkout.
Low stock: 4 left
Couldn't load pickup availability
SANDVIK CORO DRILL
8MM SOLID CARBIDE DRILL
Material classification level 1(TMC1ISO)
Cutting diameter(DC)
0.315 inch
Achievable hole tolerance(TCHA)
H8
Usable length(LU)
1.626 inch
Usable length diameter ratio(ULDR)
5.162
Adaptive interface machine direction(ADINTMS)
Cylindrical shank (DIN6535-HA) -metric: 8
Connection diameter tolerance(TCDCON)
h6
Grade(GRADE)
2214
Substrate(SUBSTRATE)
HC
Coating(COATING)
PVD TiAlN
Basic standard group(BSG)
DIN 6537 L
Coolant entry style code(CNSC)
4: axial concentric entry on circle
Coolant pressure(CP)
290.075 lbf/in2
Connection diameter(DCON)
0.315 inch
Point angle(SIG)
140 deg
Point length(PL)
0.0512 inch
Overall length(OAL)
3.5827 inch
Functional length(LF)
3.5315 inch
Chip flute length(LCF)
2.0866 inch
Maximum regrinds(NORGMX)
3
Rotational speed maximum(RPMX)
3,820 1/min
Weight of item(WT)
0.1235 lb
Release date(ValFrom20)
2014-02-25
Release pack id(RELEASEPACK)
14.1
