Tool cutting edge angle (KAPR)

98 deg

Lead angle(PSIR)

-8 deg

Corner radius (RE)

0.2 mm

Depth of cut maximum (APMX)

0.5 mm

Connection - machine side(ADINTMS)

CoroTurn XS -metric: 6

Maximum ramping angle (RMPX)

0 deg

Minimum bore diameter(DMIN1)

6.2 mm

Maximum overhang (OHX)

33 mm

Usable length (LU)

30.5 mm

Hand (HAND)

R

Chip breaker(CBMD)

A

Grade (GRADE)

1025

Substrate(SUBSTRATE)

HC

Coating(COATING)

PVD TiAlN+TiN

Coolant entry style(CNSC)

0: without coolant

Coolant exit style(CXSC)

0: no coolant exit

Connection diameter(DCONMS)

6 mm

Functional length(LF)

52.25 mm

Functional width(WF)

2.95 mm

Functional height(HF)

0 mm

Body width(WB)

5.7 mm

Body material(BMC)

Carbide

Weight of item(WT)

0.025 kg
