Sandvik Solid Carbide Subland Step Drill 16mm Body 15.1mm Step Dia Coolant Thru
Sandvik Solid Carbide Subland Step Drill 16mm Body 15.1mm Step Dia Coolant Thru
Regular price
$48.04 USD
Regular price
$0.00 USD
Sale price
$48.04 USD
Unit price
/
per
Shipping calculated at checkout.
Free Shipping:
Available on all orders over $75 in value, shipping to the lower 48 states. Refer to our
Shipping Policy for more details.
Same-Day Shipping & Handling Cut-Off Time: Orders placed before 3:00 PM (EST) Monday through Friday, ship on the same business day.
No Returns Or Exchanges: Being in the wholesale business we offer our products at well below regular prices, for the intent of resale. Therefore, we do not accept returns or exchanges. Refer to our Refunds Policy for more details.
12 in stock
Couldn't load pickup availability
SANDVIK
SOLID CARBIDE SUBLAND STEP DRILL BIT
| Drill Body Size (mm) | 16 |
| Drill Body Size (Decimal Inch) | 0.6299 |
| Step Diameter (mm) | 15.10 |
| Step Diameter (Decimal Inch) | 0.5945 |
| Shank Type | Straight |
| Shank Diameter (Decimal Inch) | 0.6299 |
| Drill Bit Material | Solid Carbide |
| Drill Bit Finish/Coating | Multilayer TiAlN |
| Overall Length (Decimal Inch) | 4.8819 |
| Step Length (mm) | 35.00 |
| Step Length (Decimal Inch) | 1.3780 |
| Specification Designation | ANSI; DIN; ISO |
| Flute Length (mm) | 53.00 |
| Flute Length (Decimal Inch) | 2.0870 |
| Shank Length (Decimal Inch) | 1.8898 |
| Shoulder Included Angle | 90 |
| Drill Point Angle | 144 |
| Tap Thread Size | 1/2-20 |
| Specification Number | DIN1835-A/DIN6535-HA |
| Drill Bit Diameter Tolerance (mm) | m7 |
| Series/List | CoroDrill 860 |
| Through Coolant | Yes |
